Solar Charger Controller 12V/24V Dual USB 10A 20A 30A Battery Charge Regulator Solar Panel Controller And PWN Controller
|
MODEL |
PWM-E-10A |
PWM-E-20A |
PWM-E-30A |
PWM-E-40A |
PWM-E-50A |
PWM-E-60A |
|
Battery Voltage |
12V 24V Auto |
|||||
|
Charging Current |
10A |
20A |
30A |
40A |
50A |
60A |
|
Discharging Current |
10A |
10A |
10A |
20A |
30A |
30A |
|
Max Solar input |
48V(for 24V battery) 24V(for 12V battery) |
|||||
|
Equalization |
14.4V(Sealed) 14.2V(Gel) 14.6V(Flood) |
|||||
|
Float charge |
13.7V(Defaul,adjustable 12.7V-15V) |
14.4V(Sealed) 14.2V(Gel) 14.6V(Flood) Adjustable 13V-15V |
||||
|
Discharge stop |
10.7V(Defaul,adjustable 9V-11.3V) |
10.7V(Defaul,adjustable 9.5V-11V) |
||||
|
Discharge reconnect |
12.6V(Defaul,adjustable 11.5V-13V) |
12.6V(Defaul,adjustable 11.5V-13V) |
||||
|
Charge reconnect |
13V |
|||||
|
Voltage of open light |
Solar Panel 8V(Light lights delay) |
|||||
|
Voltage of close light |
Solar Panel 8V(Light off delay) |
|||||
|
USB output |
5V/2A |
|||||
|
Self-consume |
<10mA |
|||||
|
Operating temperature |
-35°C~+60°C |
|||||
|
Size |
133.5*70*35mm |
188*90*47mm |
||||
The float charge voltage,discharge stop voltage,discharge reconnect voltage in excel is for 12V system,If 24V system,please multiply by2
Specifications：
Warmly Tips:
- The reverse order applies when deinstalling!
- An improper sequence order can damage the controller!
- All red color voltage x2, while using 24V system.
- This solar controller is not waterproof, please install it indoor or out of the rain.
- This controller is only suitable for various lead-acid batteries(including openings,sales,gels,etc.),please do not use it to charge other batteries (including lithium batteries,nickel-metal hydride batteries,ect.
Features:
- Upgraded version of solar panel controller: Compatible with 12V 24V system. This solar controller helps you automatically manage the work of the solar panels and batteries in your solar system using a built-in industrial microcontroller. No need to reset when the battery runs out, because it remembers various parameters set by the user. You can also charge your phone, tablet, PC with dual USB outputs up to 5V/2.5A.
- Safe to use: Equipped with overcurrent protection, short circuit protection, reverse connection protection, low voltage, overcharge protection, with full 3-stage PWM charging management. This 30A solar charge controller will help you safely increase system efficiency and extend battery life.
-
LCD Display: The LCD display keeps you informed of status and data. You can also easily switch modes and parameter configurations, and you can use the controller in different places such as home, industry, and business.
- Multiple electrical protections: Built-in over current protection, short circuit protection, reverse polarity protection, open circuit protection, automatic recovery, and no damage to the controller, providing reliable protection for your equipment.
- Good heat dissipation: Double MOSFET reverse current protection, low heat generation, all electronic components will heat up during the working process, it is best to shade them for better heat dissipation, and avoid direct sunlight or humid places.
Descriptions:
The LCD display keeps you informed of status and data. You can also easily switch modes and parameter configurations, and you can use the controller in different places such as home, industry, and business. Built-in over current protection, short circuit protection, reverse polarity protection, open circuit protection, automatic recovery, and no damage to the controller, providing reliable protection for your equipment.
- The reverse order applies when deinstalling!
- An improper sequence order can damage the controller!
- All red color voltage X2 ,while using 24V system.
- This solar controller is not waterproof ,please install it indoor or out of the rain.
