Caracteristici
1.Mppt Invertor solar cu undă sinusoidală pură
2.Factor de putere de ieșire 1.0
3.WIFI Inlcuded--WIFI/ PC Online Monitor Support
4. Working With Or Without Battery,Max charging current 120A
5.Built-in anti-dusk kit for harsh environment,Stop the Bug,extend Life Span
6.Smart battery charge design to optimize battery life
7.ON/OFF Grid Function
8.Cold Start
9.AGM/FLOOD/Lithium Battery Support Bulk/Float/Low Cut Off Voltage Adjustable
If Using Lithium Battery, for safety reasons We recommend Lifepo4 instead of ternary lithium battery
10.PV High Effeciency working voltage 250-360V
| 37 | GRID-tie operation |
Off grid (default)
|
Inverter operates only in off-gridmode Solar energy provides powertothe loadsas first priority and chargingsecond |
|
Hybrid
|
Inverter operates hybrid mode. Solarenergy provides power to the loads asfirst priority and charging secondExcess energy feed to grid. |
|
Model |
AGH-6.2KW |
|
PHASE |
1-phase |
|
MAXIMUM PV INPUT POWER |
6000W |
|
RATED OUTPUT POWER |
6000W |
|
MAXIMUM CHARGING POWER |
6000W |
|
GRID-TIE OPERATION |
|
|
PV INPUT(DC) |
|
|
Nominal DC Voltage/Maximum DC Voltage |
360VDC/500VDC |
|
Start-up Voltage/Initial Feeding Voltage |
120VDC |
|
MPPT Voltage Range |
90VDC~450VDC |
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
|
GRID OUTPUT(AC) |
|
|
Nominal Output Voltage |
220/230/240VAC |
|
Output Voltage Range |
195.5~253VAC |
|
Nominal Output Current |
26.1A |
|
Power Factor |
>0.9 |
|
EFFICIENCY |
|
|
Maximum Conversion Efficiency(DC/AC) |
97% |
|
OFF-GRID OPERATION |
|
|
AC INPUT |
|
|
AC Start-up Voltage/Auto Restart Voltage |
120-140VAC/180VAC |
|
Acceptable Input Voltage Range |
90-280VAC or 170-280VAC |
|
Maximum AC Input Current |
40A |
|
PV INPUT(DC) |
|
|
Maximum DC Voltage |
500VDC |
|
MPPT Voltage Range |
90VDC~450VDC |
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
|
BATTERY MODE OUTPUT(AC) |
|
|
Nominal Output Voltage |
48VDC |
|
Output Waveform |
Pure sine wave |
|
Efficiency(DC to AC) |
94% |
|
HYBRID OPERATION |
|
|
PV INPUT(DC) |
|
|
Maximum DC Voltage |
360VDC/500VDC |
|
Start-up Voltage/Initial Feeding Voltage |
120VDC |
|
MPPT Voltage Range |
90VDC~450VDC |
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
|
GRID OUTPUT(AC) |
|
|
Nominal Output Voltage |
220/230/240VAC |
|
Output Voltage Range |
195.5~253VAC |
|
Nominal Output Current |
26.1A |
|
AC INPUT |
|
|
AC Start-up Voltage/Auto Restart Voltage |
120~140VAC/180VAC |
|
Acceptable Input Voltage Range |
90~280VAC or 170~280VAC |
|
Maximum AC Input Current |
40A |
|
BATTERY MODE OUTPUT(AC) |
|
|
Nominal Output Voltage |
220/230/240VAC |
|
Efficiency(DC to AC) |
94% |
|
BATTERY & CHARGER |
|
|
Nominal DC Voltage |
48VDC |
|
Maximum Solar Charging Current |
120A |
|
Maximum AC Charging Current |
80A |
|
Maximum Charging Current |
120A |
|
GENERAL |
|
|
PHYSICAL |
|
|
Dimension, D*W*H(mm) |
420*310*120 |
|
Net Weight(KGS) |
13 |
|
INTERFACE |
|
|
Communication Port |
WIFI |
|
ENVIRONMENT |
|
|
Operating Temperature |
0℃~90℃ |
|
Storage Temperature |
-10℃~50℃ |
|
|
Monitor
Asistență pentru monitorizarea și setarea online (dacă aveți nevoie de demonstrație, contactați-ne prin mesaj, vă vom trimite linkul pentru videoclip)
Cea mai mare parte a valorii poate fi setarea operațiunii vizualizate online
Poate monitoriza mai multe dispozitive suplimentare, ajută la o gestionare masivă
Suportă setarea și monitorizarea aplicației pentru telefon
