Daxtromn Hybrid Solar Inverter 3600W 2 AC Out Put 24v Battery 120A DC 6000w PV Input 120VDC-450VDC Input
| 37 | GRID-tie operation |
Off grid (default)
|
Inverter operates only in off-gridmode Solar energy provides powertothe loadsas first priority and chargingsecond |
|
Hybrid
|
Inverter operates hybrid mode. Solarenergy provides power to the loads asfirst priority and charging secondExcess energy feed to grid. |
|
Model |
AGH-3.6KW |
AGH-6.2KW |
|
|
PHASE |
1-phase |
||
|
MAXIMUM PV INPUT POWER |
6000W |
||
|
RATED OUTPUT POWER |
3600W |
6000W |
|
|
MAXIMUM CHARGING POWER |
6000W |
||
|
GRID-TIE OPERATION |
|||
|
PV INPUT(DC) |
|||
|
Nominal DC Voltage/Maximum DC Voltage |
360VDC/500VDC |
||
|
Start-up Voltage/Initial Feeding Voltage |
120VDC |
||
|
MPPT Voltage Range |
90VDC~450VDC |
||
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
||
|
GRID OUTPUT(AC) |
|||
|
Nominal Output Voltage |
220/230/240VAC |
||
|
Output Voltage Range |
195.5~253VAC |
||
|
Nominal Output Current |
15.7A |
26.1A |
|
|
Power Factor |
>0.9 |
||
|
EFFICIENCY |
|||
|
Maximum Conversion Efficiency(DC/AC) |
97% |
||
|
OFF-GRID OPERATION |
|||
|
AC INPUT |
|||
|
AC Start-up Voltage/Auto Restart Voltage |
120-140VAC/180VAC |
||
|
Acceptable Input Voltage Range |
90-280VAC or 170-280VAC |
||
|
Maximum AC Input Current |
30A |
40A |
|
|
PV INPUT(DC) |
|||
|
Maximum DC Voltage |
500VDC |
||
|
MPPT Voltage Range |
90VDC~450VDC |
||
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
||
|
BATTERY MODE OUTPUT(AC) |
|||
|
Nominal Output Voltage |
24VDC |
48VDC |
|
|
Output Waveform |
Pure sine wave |
||
|
Efficiency(DC to AC) |
94% |
||
|
HYBRID OPERATION |
|||
|
PV INPUT(DC) |
|||
|
Maximum DC Voltage |
360VDC/500VDC |
||
|
Start-up Voltage/Initial Feeding Voltage |
120VDC |
||
|
MPPT Voltage Range |
90VDC~450VDC |
||
|
Number of MPPT Trackers/Maximum Input Current |
1/27A |
||
|
GRID OUTPUT(AC) |
|||
|
Nominal Output Voltage |
220/230/240VAC |
||
|
Output Voltage Range |
195.5~253VAC |
||
|
Nominal Output Current |
15.7A |
26.1A |
|
|
AC INPUT |
|||
|
AC Start-up Voltage/Auto Restart Voltage |
120~140VAC/180VAC |
||
|
Acceptable Input Voltage Range |
90~280VAC or 170~280VAC |
||
|
Maximum AC Input Current |
30A |
40A |
|
|
BATTERY MODE OUTPUT(AC) |
|||
|
Nominal Output Voltage |
220/230/240VAC |
||
|
Efficiency(DC to AC) |
94% |
||
|
BATTERY & CHARGER |
|||
|
Nominal DC Voltage |
24VDC |
48VDC |
|
|
Maximum Solar Charging Current |
120A |
||
|
Maximum AC Charging Current |
80A |
||
|
Maximum Charging Current |
120A |
||
|
GENERAL |
|||
|
PHYSICAL |
|||
|
Dimension, D*W*H(mm) |
420*310*120 |
||
|
Net Weight(KGS) |
11 |
13 |
|
|
INTERFACE |
|||
|
Communication Port |
WIFI |
||
|
ENVIRONMENT |
|||
|
Operating Temperature |
0℃~90℃ |
||
|
Storage Temperature |
-10℃~50℃ |
||
