| MODEL | AOH-2KVA | |
| RATED POWER | 2000VA/1600W | |
| AC Input | ||
| Voltage | 230VAC | |
|
Selectable Voltage Range |
170-280VAC(For Persional Computers) | |
| 90-280VAC(For Home Appliances) | ||
| Frequency Range | 50 Hz/60Hz(Auto sensing) | |
| AC Output | ||
| AC Voltage Regulation | 230VAC±5% | |
| Surge Power | 4000VA | |
| Efficiency(Peak)PV to INV | 98% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10 ms (For Persional Computers);20 ms (For Home Appliances) | |
| BATTERY & AC CHARGER | ||
| Battery Voltage | 12VDC | |
| Floating Charge Voltage | 13.5VDC | |
| Overcharge Protection | 16VDC | |
| Maximum AC Charge Current | 60A | |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 2000W | |
| MPPT Range @ Operating Voltage | 30~400VDC | |
| Maximum PV Array Open Circuit Voltage | 400VDC | |
| Maximum Charging Current | 80A | |
| PHYSICAL | ||
| Dimension,D*W*H(mm) | 357*273*95 | |
| Carton Dimension,D * W *H(mm) | 440*340*170 | |
| Net Weight(kgs) | 5 | |
| Gross Weight(kgs) | 6 | |
| Communication interface | RS232/GPRS/WIFI | |
