    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter
    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter

    3.5KW solar inverter MPPT 100A AC 220V DC 48VDC 500VDC PV input 5000W Pure Sine Wave hybrid inverter

    Save $35.00 USD $245.00 USD $280.00 USD
    Ship From
    China
    Quantity
    Only 994 left
    Inventory quantity: 994
    Buy now
    Europion Union Fast shipping
    Free returns
    Carbon neutral
    Secure payments









    Rated Power

    3500VA/3500W



    Input



    Voltage

    230VAC

    Selectable Voltage Range

    170~280VAC(For Personal Computers)

    90~280VAC(For Home Appliances)

    Frequency Range

    50Hz/60Hz(Auto sensing)

    Output



    AC Voltage Regulation(Batt.Mode)

    230VAC±5%

    Surge Power

    7000VA



    Efficienc(Peak)PV to INV

    97%

    Efficienc(Peak)Battery to INV

    94%

    Transfer Time

    10ms(For Pensonal Computers);20ms(For Home Appliances

    Battery & AC Charger



    Battery Voltage

    24VDC



    Floating Charge Voltage

    27VDC



    Overcharge Protection

    33VDC



    Maximum Charge Current

    80A



    Solar Charger



    Maximum PV Array Power

    5000W



    MPPT Range @ Operating Voltage

    120~450VDC

    Maximum PV Array Open Circuit Voltage

    500VDC

    Maximum Charging Current

    100A



    Maximum Efficiency

    98%

    Physical





    Dimension,D*W*H(mm)

    100*300*440

    Net Weight(kgs)

    11



    Communication Interface

    USB/RS232/GPRS/WIFI

    Operating Environment



    Mumidity

    5% to 95% Relative Humidity(Non~condensing)

    Operating Temperature

    0℃~55℃

    Storage Temperature

    -15℃~60℃
